How to install the winch on the front bar?

If you already have an original or imitated big stick, you can check for a Fromwinch synthetic rope ATV winch installation (usually there is one), then choose any built-in off-road winch can be installed directly into. If the installation of the competitive bar, you can make a very typical external installation. If in some urban SUV (such as high-handed) installation, generally do not want to damage the front face too much, with a simple tray rack for built-in installation is feasible. If you plan to change a little personality, professional point, to find custom bar before the modified plant, you can play any of the.
Continued • Problem with the size of the winch
(Only for) off-road winch installation dimensions are in fact the international standard, the installation hole distance is 254mm * 114.3mm (inch 10 "* 4.5"), a winch position on the front bar has been drilled the appropriate size Mounting holes. Winch overall size of the gap is small, basically 570mm * 180mm * 170mm or so, the user can choose when measuring the installation space, and access to the parameters of the Fromwinch twin motor winch. If the external installation, basically do not consider the winch size, or even directly select a dedicated external style.

Winch speed

Normally you will read about the speed of the Fromwinch electric winch 4x4 in the off-road winch tutorial which is essential, and should actually be treated with a rational need. For example, the WARN XD9000 uses a 4.6 hp motor and the no-load loop 11.6 m / min. At 9,000 lb, the loop speed is 1.94 m / min and the current is 460 amps. The CHAMPION G9000 uses a 3.6 hp motor, The WS 9500I uses a 6.0 hp motor with a no-load return line of 12.8 m / min. At 9500 lb. of tension, the return wire is at a speed of 1.5 m / min and a current of 280 amps at 9,000 lb / The speed is 1.9 m / min and the current is 350 amps. (2) "high-speed" is mainly reflected in the no-load or low load, the speed advantage of heavy load when the load is no longer obvious (1) high-speed winch use more powerful motor, battery consumption faster; .
Therefore, in addition to the need to participate in the process of rapid rescue game, and the need to quickly recover the rope after the rescue (in fact, after the random entanglement in the rescue after the end of the line to recover the finishing line), no more The absolute demand for Fromwinch 12500lbs winch, and general speed winch is relatively more favorable

Hand Winch Installation Method

1. Install the Fromwinch rhino hand winch: remove the winch from the box, the chassis down, wire rope outlet placed in front of the installation platform, the platform pre-hexagonal screw or trailer alignment winch base round hole or groove can be.
We can install trailer hook, trailer ball, trailer tees, etc., which are required for the winch, and your winch supplier may have recommended products.
2, the installation of wire rope: winch delivery customers have pre-installed wire rope. If you need to replace or lengthen the rope, please use the handle to control the Fromwinch car electric winch and the appropriate rope to do the traction, remove the original wire rope, Fromwinch 4WD Electric Winch drum on the left side of a hexagonal bolt fixed wire rope ends,
3, the installation handle: the handle only when you need to install the work, unscrew the left side of the exposed cap nut, the handle screw end clockwise screw into the exposed screw, and then tighten the nut.

Off-road vehicle winch walking wheel brake is a manual expansion brake brake

Fromwinch electric crane winch walking wheel brake device is a manual expansion valve brakes, winch wheel mounted inside the wheel wheel. In the choke, the device control handle so the tractor driver's seat next to the encounter downhill or emergency situations, can immediately manipulate the handle brake. Control walking speed or avoid accidents. Start spraying operation. And then the joystick on the winch car, and to winch car walking wheel in the brake bulging condition. Then the winch car on both sides of the brake support sticks down to anchor, so that you can ensure winch sprayer spraying operation stability.
Fromwinch portable truck winch is the most common, driven by the vehicle's own power. Its advantage is that in the case of car off the basic normal use, is unmatched by the other winch, especially for the advantages of water and more highlights, simple installation, installation speed, location and more choices.

Fromwinch high speed winches are designed for easy operation and rock-solid durability

Fromwinch high speed winches, available in capacities from 20 to 90 tons, are designed for easy operation and rock-solid durability. The heavy duty winch

, sprockets, and roller bearings are exceptionally strong, and the phosphor bronze bearings can take whatever you can dish out. Thermostatically protected motors, machined alloy gearing, and NEMA 4 spring-loaded electric brakes make our towboat winches a study in strength. We offer 208V or 230/460V 3- phase, 60Hz high-torque motors, with other voltages, and special marine motors available.

any winch would help get you out of

electric atv winch go hand in hand much like passenger cars and cup holders. If you like to explore the unpaved world, chances are you could get in a jam that any winch would help get you out of. Chances are even greater that having a winch on your quad can rescue someone else. According to our surveys, a winch is the number one accessory installed on a utility ATV. Even off the trail, winches can come in handy with all kinds of chores. One of the latest winches to hit the market, fortunately, is one of the most affordable too.
As with most machines, most winch installs require the use, purchase and mounting of a winch plate. One of the most popular winch mounts known is the heavy-duty product from Fuse Powersports. For the rhino hand winch

, the winch mount will provide power to the winch system.

Fromwinch high speed winches Mainly used for installing and disassembling large and oversize concrete

Fromwinch high speed winches

, Hydraulic Towing Winches Brief description: Mainly used for installing and disassembling large and oversize concrete and steel structure and mechanical equipments. Fit for engineering site managed roads , bridges , engineering equipments installation of large factories and mines , ports shipyard.
high quality winch is mainly used in the large and middle sized concrete, steel structure and mechanical equipment installation and dismantling. The structural characteristics of steel wire rope is an orderly, lifting safe and reliable. Suitable for all kinds of bridge, port, wharf and road and bridge engineering and large factories and mines engineering equipment installation.

How to use the Fromwinch two motor winch with the winch to save the wreck vehicle accident First of all, according to the situation of the vehicle and the terrain conditions, choose a good car to save the parking location, tighten the hand brake, and then the triangle before the rear wheel
Plug tight. Second, adjust the direction of the wheel wrecked vehicle, right twist drag direction, if necessary, to dig up the rut, and then twisted drag. If you are limited by terrain or power shortage, you can use the pulley to change the direction of force, increase traction, twist dragging b6, in the traction around the station can not be people, such as rope loose or other abnormal circumstances, pro-immediately stop checking to Anti-accident.

How to Use the Automobile Winch Properly

Correct operation of the fromwinch electric winch 3000lbs:
1, when used, to ensure that the ground is stable, if the tilt will be a great security risk.
2, should be based on the manual, the weight must not exceed the load of the machine itself, more than words, it is easy to cause mechanical damage.
3, some parts of the car winch can often change, we sell, will be presented the corresponding parts, will be more flexible machinery.
4, do not arbitrarily home lengthening the handle of the fromwinch car electric winch, different length of the handle carrying different forces, so you have to follow the standard operation.
5, always check whether there is loosening, to avoid the occurrence of security incidents.
6, do not use, they have to do dust control measures, plus some maintenance measures.

Details of the car winch

Car winch is a use of its own power engine rotation, through the other side of the fixed or traction rope or special cable to the car pulled out of trouble in a tool that is one of the necessary tools for off-road vehicles.
Automobile winch works: through external power, into the cable pull, so that the car can not move out of the woods, of course, it can also help the driver to remove obstacles on the road.
fromwinch electric towing winch is mainly used for off-road vehicles, agricultural vehicles, ATV sports cars, yachts, and other special vehicles, vehicles, ships and self-protection and traction device. Can be in the snow, swamps, deserts, beaches, muddy mountain road and other harsh environments for self-help vehicles, and may be in other conditions, the barrier, drag goods, installation facilities, military police, oil, hydrology, Forestry, transportation, public security, border defense, fire and other field sports indispensable safety devices.
There are a variety of car winch, there are electric winch, mechanical PTO winch, hydraulic PTO winch, hydraulic winch, etc., of which the most popular electric winch is also the most familiar.
Electric winch is obtained from the car battery power to drive the motor, driving noose. This winch is very convenient to use, because you can stand anywhere, through the remote control knob to manipulate the fromwinch electric winches for trucks. This winch has an advantage, that is, even if the engine does not start up, as long as there is electricity in the battery, you can control the winch.
Mechanical PTO winch due to direct force on the engine, so the torque is super, toughness and durability are very good, but the drawback is that the car turned over, the engine can not be used when the operation is not, and its size and weight are great for Of the model is quite limited.
Hydraulic PTO winch need to install a special pump connected to the engine, not only heavier and more complex installation.
fromwinch atv synthetic winch rope pulling speed constant and not fast, it is also very complex to install, and it uses the original car steering power of the oil system, will be "thin" of its oil pressure, not suitable for any car to be modified on the powerful Of the booster pump was more at ease, but it is not too much heat trouble.

Car winch common sense:

The working mechanism inside the fromwinch electrical cable winch is: the power from the car to drive the motor first, and then drive the drum motor rotation, drum and drive the drive shaft, the drive shaft and then drive the planet gear, and then have a strong torque. Subsequently, the torque is transmitted back to the drum, the drum will drive the winch. There is a clutch between the motor and the gear unit that can be switched by a handle. Braking unit in the drum, when the noose tension, the drum is automatically locked.
Winch manufacturer Hongbin introduced winch several accidents
1, the fromwinch 4000lbs electric winch relay or even the entire motor burned;
2, due to the emergence of these two issues, resulting in winch operators and spectators were hurt. If the vehicle is in a dangerous position (such as Banpo or partially vacant), the vehicle will run out of control.
3, winch cable will be pulled off;
When buying a car winch, pay attention to winch drum. The winch drum is a cylindrical device that winds the cable. It is driven by an electric motor, and the winch cylinder can change the direction of rotation under the control of the remote control.

The role of car winch:

1.fromwinch 9600lb electric winch is used for car self-help, rescue, towing, can also be used for road wrecked rescue vehicle towed fault car and engineering installation, oil field drilling and other field pull heavy objects; car winch (Winch) is a vertical The fromwinch electric winch for tower, which is a vertical winch with the axis of rotation and the deck, is the self-protection and traction device of the vehicle and vessel. It can be self-rescued and applied in harsh environments. Saving, mainly used for off-road vehicles, agricultural vehicles, ATV all-terrain vehicles, yachts, fire rescue vehicles, road wrecker and other special vehicles, special vehicles.
2. Product advantages:
This product can work with the host long-term in the wild, which is characterized by compact, small size, light weight, large tension, easy installation and easy maintenance.

An overview of the car winch

fromwinch heavy duty synthetic rope winch is a mechanical tool, it is by hand shake the winch drum to pull the goods. A gear-driven winch wire reel pulls the cargo by rotating a wire rope over it.
Car winch installation process to explain:
1, install the winch: open the package, remove the winch. Turn the hex head screw and shim from the end of the gear ax. Fix the nut on the handle to the trapezoidal turbine on the end of the gear ax so that the inside of the nut is close to the friction piece. Then tighten the screws and the shims.
2, the installation of winch rope: Loosen the fromwinch electric winches for 4x4 reel on the left side of the fixed plate hexagonal screws, from the rope and the oval head, square column screws, where the fixed plate. One end of the wire rope around the drum in a clockwise direction, the other end of the fence through the left that is long and round, curved holes. Exposed wire rope length should be 7-10 cm. Will have an oval head, square column of the screw from the inside out through the left side of the scroll hole. Place the wire rope around the reel, and then pull the wire rope around the reel. When the wire rope is wound around the reel, the wire rope is inserted into the fixing plate, then tightened and tightened with the hex nut, Maintain its tension).
3. Use three screws and nuts to secure the winch to the base. The base can withstand heavy loads.

The advantages of car winch:

1, it has an automatic brake device, when the fromwinch competition auto Winch wire rope pulling the goods, and the winch reel is not moving, the brake will automatically open the employment, which makes the operation more human and more secure. So the fromwinch competition car Winch with security.
2, it is the biggest advantage of the two is easy to carry, is another excellent choice for vehicle winch, when the need for a variety of rescue work. It can be connected in any direction from the car, light and strong. So the car winch is simple.

Safety precautions for car winch:

1, can not use this winch to pull or move people.
2, not overloaded.
3, if the rope has been damaged, broken, peaceful rust or knot, do not use.
4, when working, not the end of the wire rope pull the buckle in the rope, so as not to wear wire rope.
5, when pulling the goods, wire rope and reel should be kept perpendicular, or easy to wear wire rope.
6, when the fromwinch heavy duty synthetic rope winch with heavy load, it is best to use the pulley to reduce the winch and wire rope load.
7, when the rope around the reel less than 5 laps, do not use the winch pull the goods. Otherwise, the fixed plate will not bear the burden of accidents.
8, when the winch work, do not touch the wire rope, reel or pulley, need to organize wire rope, please wear a glove with a thick cloth to cover the rope.

Inspection and maintenance of car winch:

1.Check the brake before each use. Do not use the brake not working.
2, Before each use to check the wire rope, wire rope in order to use the fromwinch heavy duty winch cable, or must first replace the wire rope.
3, often check the screws, nuts and winch parts of the fixed situation.
4, to keep the wire rope clean, flexible, timely cleaning of wire rope dust and corrosion of steel wire rope chemical substances.

Installation and Principle of Electric Winch for Automobile Safety

If the car stuck in any place and can not extricate themselves, then the most reliable tool is the electric winch. If you learn to use the fromwinch electric winch for tower correctly, you can cross-country encountered in the course of emergency self-help and rescue each other calmly, so as to maximize the enjoyment of the four-wheel drive cross-country fun.
Electric winch installation
The use of an electric winch will of course start from the installation. This step is not complicated, but it is the most important step, because it is directly related to the subsequent steps and the use of electric winch effect. Specific installation process is as follows:
1. Insert the remote control. Insert the remote control connector end into the electric winch.
2, do not let the fromwinch two motor winch remote control hanging drape. If you are a driver, operating the remote control in the driver's seat, then the excess connection around the side mirrors in the car side, the work will be much more convenient.
3, pull the electric winch cable, with the remote control will be released a little noose and then open the winch installed on the side of the noose hook.
4, open the electric winch clutch. Be sure to turn on the hook and then turn the clutch on again.
5, holding the electric winch with a hand noose hook. When the noose is pulled down from the drum, hold the hook with one hand, so that no matter how long it is pulled, it will not be able to reach the hook.
6, the electric winch cable to the fulcrum, the clutch.

Wrecker electric winch in use, the hydraulic winch wrecker sometimes there will be some failures, common hydraulic winch wrecker phenomenon:

1, electric winch or motor oil leakage
Mainly hydraulic electric winch wrecker long-term use, electric winch seal damaged or loose bolts, as long as the replacement of electric winch seals and electric winch to tighten the connection bolts can be.
2, electric winch clutch separation, joint poor
Hydraulic electric winches wrecker clutch claw dislocation or clutch operating mechanism in question, hydraulic electric winch rotating drum to align the paw and check and remove the operating mechanism failure can be.
3,fromwinch Winch Cable Dampener work, the pressure instability and trembling
Mainly the electric winch load instability and electric winch rope rope chaos caused by re-electric winch row of steel wire rope can be (in the electric winch hook to increase the weight to avoid no-load rope).
Wrecker electric winch to regular maintenance, in order to protect the safe use of electric winch and extend the life of electric winch. To regularly replace the electric winch box of oil, generally replaced once a year.
Always check the electric winch, the motor whether there is leakage. Always check the electric winch installation bolts are loose, we must always check the electric winch wire rope broken, wear, deformation, and regular use of lubricants on electric winch wire rope lubrication, to scrap the conditions of electric winch wire rope, be sure to replace the new electric Winch wire rope.
In general, to strictly follow the specification requirements to use, maintenance and maintenance of fromwinch 12500lbs electric winch, in order to make good use of electric winch and wrecker.

Hydraulic electric winch wrecker

Hydraulic electric winch has been widely used in the wrecker, hydraulic electric winch is an important functional components, fromwinch two motor winch winches are often used for lifting and towing traction operation, hydraulic electric winch from light to heavy there are many specifications , Commonly used hydraulic electric winch with hydraulic worm winch hydraulic winch and planetary gear reducer hydraulic fromwinch electric clutch winch two types of structure, electric winch driven by hydraulic motors, electric winch deceleration device to achieve speed and increase the output torque of the purpose, in order to achieve electric Relative capacity of the winch.
Electric winch Worm hydraulic electric winch structure is relatively simple, easy to manufacture electric winch, electric winch drive efficiency and production costs are relatively low, electric winch is generally used in light fromwinch atv winch with remote control....

Car winches with the specific steps of the drag:

1, first check the fromwinch electric winches for trucks drum wheel. Before starting the car winch, make sure that the car winch is neatly wound around the car winch drum.
2, if the car winch rope out, should prevent the car wandering back and forth. If the car winches are broken, the winches of the motor winch can be very dangerous. However, this danger can be avoided, as long as the tension in the car winches on a mat placed on the line.
3, start using the car winch drag, if the car winch cable pull their own car, and you have to drive in the car winch car, it is best to have a car in the car to help you winch. In this way, the vehicle winch car driver can be in accordance with the command of the car outside the command, in the car manipulation of the car winch.
4, if the fromwinch electric clutch winch twisted cable together, we must pull the car winch. An automobile winch cord is easily crossed or worn on one side when wound around an automobile winch drum. Therefore, pay close attention to the status of car winch.
5, when the car winch car free to walk, the use of car winch drag to complete. Once back on the floor, check the car wagon for vehicle and line conditions. If you can not rely on external driving car winch car, the use of car winch drag the process is over.
6, the car winch cable is good. Tauten the car winch rope, carefully sent back. If the car winch cord cross on the car winch drum or twisted, first completely untied, and then re-roll.
7, and finally put the car winch hook. When the end of the car winch only the last point, the car winch hook tied to the side of the car winch. And then the rest of the car winch rope rolled up, the fromwinch electric winch for tower hook to suppress.

Install the car winch The specific installation process is as follows:

1, insert the fromwinch 4500lbs electrical winch remote control. Insert the car winch remote control connector end into the car winch.
2, do not let the car winch remote control hanging drape. If you are a car winch car driver, in the car winch car driver's seat on the car winch remote control, then the excess car winch connection around the car winch car side mirrors, so that the installation of the car winch will work together will be convenient many.
3, pull the car winch rope, with the car winch remote control will be a little winch cable car and then open the cable installed in the car winch side of the noose hook.
4, open the fromwinch electric truck winch clutch. Note that you must open the car winch hook and then open the car winch clutch.
5, hand holding the car winch rope hook. When the car winch rope is pulled down from the drum, hold the car winch hook with one hand, so that no matter how long the car winch cable pulls, it will not be able to reach the car winch hook.
6, the car winch cable to pull the car winch fulcrum, lock the car winch clutch.
At this point the fromwinch 12500lbs electric winch is ready.

Self - help device for off - road vehicle winch

Off-road vehicles due to poor driving conditions, often equipped with off-road vehicle winch as a self-help device. When the car wheel into a particularly loose to save the soil, or in the ice on the road surface can not travel, and fall into the pit of the hinge, you can use their twist to the end of the rope fixed in a nearby reliable location. 2. The fromwinch electric wireline winch rope twisted by the engine lifted the car out of the woods. See also You can also use it to rescue other troubled vehicles. General car winch mainly by force box, drive shaft, winch, reducer, drum Jane and automatic brakes and accessories and other components.

In fact, the winch this thing is called the hoist in the industry, because your car into a quagmire bunker or a steep slope can not move when this time we must rely on the fromwinch heavy duty synthetic rope winch, the winch can make your car from 4X4 into 4X5, ha ha, Therefore, others generally referred to as the fifth drive winch, electric winch has been the main form of off-road vehicles with the winch. Winch model means that the winch traction, the principle of choosing the winch is generally 1.5 times the weight of the vehicle weight is appropriate, as well as winch models will be marked the traction of the fromwinch high speed electric winch.

Car winches with the specific steps of the drag:

1, first check the fromwinch electric towing winch drum wheel. Before starting the car winch, make sure that the car winch is neatly wound around the car winch drum.
2, if the car winch rope out, should prevent the car wandering back and forth. If the car winches are broken, the winches of the motor winch can be very dangerous. However, this danger can be avoided, as long as the tension in the car winches on a mat placed on the line.
3, start using the car winch drag, if the car winch cable pull their own car, and you have to drive in the car winch car, it is best to have a car in the car to help you fromwinch electric crane winch. In this way, the vehicle winch car driver can be in accordance with the command of the car outside the command, in the car manipulation of the car winch.
4, if the car winch twisted cable together, we must pull the car winch. An automobile winch cord is easily crossed or worn on one side when wound around an automobile winch drum. Therefore, pay close attention to the status of car winch.
5, when the car winch car free to walk, the use of car winch drag to complete. Once back on the floor, check the car wagon for vehicle and line conditions. If you can not rely on external driving car winch car, the use of car winch drag the process is over.
6, the car winch cable is good. Tauten the car winch rope, carefully sent back. If the car winch cord cross on the car winch drum or twisted, first completely untied, and then re-roll.
7, and finally put the fromwinch electric winches for trucks hook. When the end of the car winch only the last point, the car winch hook tied to the side of the car winch. And then the rest of the car winch rope rolled up, the car winch hook to suppress.

Winch, off-road essential goods one

Off-road vehicles in addition to lifting the suspension system, coupled with non-slip differential to improve off-road capability, the winch (fromwinch electric wireline winch) is also very important one of the accessories. In the West, the Army had at least one winches per 10 four-wheel-drive trucks, which did not include the Engineering Recycling Vehicle (which was a chassis made up of 6x6, 8x8 heavy-duty trucks or more than 50 tonnes of tanks It is a large car with 2-4 winches, specifically to rescue in the field into a deep pit truck-style tanks). fromwinch high speed electric winch the importance of this can be seen.

Expansion of the application of the fromwinch Winch Cable Dampener and reducer: a buffer valve with the axial piston hydraulic motor and planetary gear mechanism composed of slewing mechanism. The upper frame is mounted on a single row spherical integral slewing ring which can rotate 360 degrees continuously. The whole system can be applied to excavators, loaders, cranes and other construction machinery. Other include: two-speed electric winch, variable speed hydraulic fromwinch 12500lbs electric winch, hydraulic rotary mechanism, hydraulic winch Worm, two-speed heavy duty hydraulic winch and heavy duty hydraulic winch and other engineering fromwinch electric winches for 4x4 system.

fromwinch heavy duty winch cable is the protection of special vehicles God: police, geology, meteorology, engineering and other work in the field of harsh and complex road conditions in the special vehicles, the need to install the Group winch, and try to keep the car after the installation, Installation principles. Heavy obstacle block car is also the Chinese armed police in recent years developed a police vehicle, equipped with front and rear winch, you can drag obstacles, great strength.

Many types of winch, electric winch, the use of automotive engine mechanical power driven winch and fromwinch electric crane winch with hydraulic pump operation, etc., off-road use up to the number of electric winch. Electric winch is from the car this
The body gains power to drive the motor to drive the noose. This type of winch is convenient because it can be operated anywhere from the knobs on the remote control. It is the biggest advantage is that as long as the battery power can be used. However, the fromwinch electric winch 3000lbs motor power of at most only 1-2 horsepower, so how can a small power motor to drag a heavy car or other heavy objects it? Secret on the use of reducer. Even if the motor can only send a small force, but the reducer can be transformed into a powerful force. Different fromwinch 12500lbs electric winch manufacturers use this principle is to create a different product.

The same is the fromwinch electric towing winch, the power part (ie motor) there are two, namely, permanent magnet motor and series motor. The former has a fast action, power, suitable for a long time and cost of high volume pull characteristics, while the latter is a small current, classical, simple structure and low cost of traditional forms. The early RAMSEY winch used a permanent magnet motor. Now the vehicle's storage capacity is large, so the current mainstream off-road vehicle winch of high-power electric motors use more series motor. Judge a fromwinch 12500lbs winch with a permanent magnet motor or a series motor, just look at the control box output to the motor part of the number of lines can understand that the two lines are permanent magnet motor and the three lines is the series excitation motor.

The Arabic numerals in the fromwinch electrical cable winch model indicate the maximum pulling force. For example, the GEW 9000 of RUNVA refers to the maximum pulling force of 9000 lb (lb is non-legal unit of measure, 1 lb = 0.45359237 kg). The principle of choosing the fromwinch winch for 4x4 is generally 1.5 times the weight of the vehicle pulling force is appropriate. Such as the Cherokee's weight is 1600kg, then the winch pull should not be less than (1600 / 0.45) x1.5 (lb) = 5333lb, it is recommended to use 8000lb and above winch. Why? Because the winch model is rated on the maximum tension, but the actual use of this is a limit. If the vehicle for a long time under the limits of the use of the engine, will inevitably affect life expectancy. Also in the limit state, the winch cable will be pulled off, the motor burned the accident, will cause serious harm bystanders, the vehicle may also be out of control. fromwinch 4000lbs electric winch may be in the work of the tension is random and unpredictable, it should be possible to install a large pull of the winch is an endless pursuit of off-road enthusiasts.

Winch where prone to failure or loss

fromwinch electric crane winch drive from the special motor, which is characterized by small size, power, current, high temperature, overload and prolonged work on the motor is fatal. In addition, although now equipped with roller-type rope guide, but at work, the rope will still have a greater wear and tear, therefore, in the fromwinch electric winch 4x4 work, try to keep a small into the rope angle, and steel Rope enough maintenance is required. Another important part is the gear, now usually used in powder metallurgy or calcined steel gear, its durability is very good, do not worry.

Obtained AN ATV? WE'VE Obtained THE WINCH!

Centered on our Amazing fromwinch best 4x4 winches, our Variety of ATV recovery Products are Constructed Difficult to get your ATV out of any sticky Circumstance. Obtainable in 3 sizes, these fromwinch heavy duty winch cable Function a planetary Supplies Program for a Rapid Collection Pace along with a Minimal voltage Energy Reducing.

The Electric Energy of this fromwinch jimmy winch is Presently supplied by two BOW Engine II. These are supplied Typically with a 12v Provide from your Automobile onto the Large Proficiency Red-colored Winch copper busbar assembly. This busbar assembly Products an Exceptional Superior Link to the motors. The Large Energy Albright solenoid packs are Employed to Change Path of the motors and to also Supply a feed to the 12v brake Technique. These are all Confirmed Elements and Broadly Obtainable and have been Employed extensively in the Competitors and motorsport Sector by fromwinch electric winches for trucks for Lots of Many years.
The Hornet as Regular if we Should Evaluate is the Very same as a Gigglepin +50 if not a Tiny Sooner...

Power of the winch is variable Credited to how your Automobile is Set up and the Superior of the Elements Employed. It also Is dependent on the scale of Electric losses or inefficiencies in the wiring Technique.
As a Basic Principle Operating 12v DC BOW Engine II with the Red-colored winch Busbar assembly with a Great Energyful Provide you can Anticipate the fromwinch electric winch for towerto Take 4.5 tonnes...possibly A lot more Below Specific Disorders. Tried with x2 Odyssey PC1500 batteries, 12V Provide and Soil Links Produced with 70mm2 Cable television.

A Higher Overall performance TWIN Engine Electrical WINCH

The Hornet is an Exceptional Selection when it Arrives to the Most excellent Levels of competition electric winching for your Automobile. fromwinch high speed electric winch has Developed and Created this high performance twin motor fromwinch electric towing winch for the 4x4 Levels of competition and motorsport Occasions. It has been Developed with the Levels of competition in Thoughts and has Various Attributes ideally suited to high performance motorsport Occasions.

Electric winch is a commonly used lifting and pulling device in many engineering projects

Electric winch is a commonly used lifting and pulling device in many engineering projects. Generally, for land construction, the most winch adopts electricity as power source. If necessary, power source of some engine winch machine could be hydraulic type and diesel type, we use to call this kind of winch as hydraulic winch and diesel winch.
Fromwinch high speed electric winch has two basic function. Firstly, lifting loads. You can lift loads in vertical direction by using an electrical winch. Secondly, electric winch machine is able to pull loads in horizontal and slant function. Fromwinch manufacturer provides you different types of electric winches according to your need. Our engine machine can be used as great helper in installing and teardown large and medium size concrete steel structure and machine equipment.

Fromwinch electric winches offer superior pulling strength

Fromwinch electric winches offer superior pulling strength while maintaining a low electric current. From the potency of a permanent magnet motor to the durability of a series wound motor. Heavy duty winch is the right choice for big jobs and unforgiving conditions. The tough aluminum alloy housings, silver-alloy contact pads, and thick copper buss bars are weather resistant, and backed by a limited lifetime warranty covering all mechanical components.
It is compact, lightweight, and flexible, yet capable of handling a wide variety of applications with ease. Whether you need to load a trailer, position cargo, or move a vehicle the Bulldog Utility Duty Winch is always reliable and ready for action. rated line pull capacity with rope and remote.

Fromwinch double motor winch feature

Fromwinch double motor winch allows the winch to be installed in tighter spaces with a remotely mounted solenoid pack. As a safety feature for the operator, the brake will automatically engage when the solenoid is inactive. Optional wireless remote operation saves time and allows the operator to monitor the recovery or winching operation from a different perspective.
Our winches feature:
Motor and solenoids grounded directly to battery
Automatic load-holding brakes for strength and reliability
4-way roller fairleads or hawse fairleads available
Winches accessories including up to wire pendant remotes, heavy-duty remotes, clevis hooks, mounting channels, safety switches, winch covers, wiring kits, grill/brush guards and bumpers available
Made in the USA

Fromwinch is a manufacturer & distributor of electric winches

Fromwinch is a manufacturer & distributor of electric winches including heavy duty hauling winches, heavy duty lifting winches & heavy duty electric winch. Heavy duty hauling winches & heavy duty lifting winches are available with 3-phase motors in different standard voltage. Heavy duty hauling winches & heavy duty lifting winches feature helical gear reducers plus high-capacity, anti-friction bearings & options include electromagnetic brake, grooved drum, free spooling system, rotary limit switches, controls, large drums & torque limiters.
Fromwinch high speed winches features includes huge 6.5 hp high quality double sealed motor with brass fittings, heavy duty waterproof contactors, double sealed drum on maintenance free bearings, quiet, fully sealed efficient full steel planetary gearing. Stainless steel roller fairlead and fittings as standard. Complete with heavy duty integrated wireless remote.

snatch block will double your load capacity

If you want to double motor winch, or if the anchor point is too close to let out enough cable for a strong pull, use a snatch block to double the line. Using a snatch block will double your load capacity and will allow you to spool out more cable to reach the maximum rating of your winch. For even more power, you can rig up a triple line pull. However, use caution with double and triple lines. As the strength of the pull increases, so does the amount of stress placed on each rigging point. Make sure your anchor point is rock solid and can withstand the force of the pull.
As your winch works harder, it generates more heat. In order to prevent overheating the motor, take breaks if you're pulling over a long distance and let the motor cool before starting again. Winching places a heavy load on your electrical system, so keep your engine running to prevent a complete drain. In some cases, a stock battery may not provide enough juice to power a maximum pull. Some wheelers swap the stock battery for a heavy duty one, or they install a second battery solely for recovery.

An double motor winch is a powerful recovery tool

An double motor winch is a powerful recovery tool. Used correctly, it provides massive amounts of power to pull out your ATV or truck high speed winches. With the right tools and rigging, you can pull up to two or even three times the maximum rating of your winch. The key to maximum power is knowing how to use your recovery equipment to its full potential. With these recovery tips, you'll be winching your way out of even the toughest spots just like the pros.
Let's focus on rigging up a single line pull. Whenever possible, choose an anchor point directly in line with the stuck vehicle. A straight line pull is more efficient than an indirect pull. If the only option is to winch at an angle, use a snatch block to guide the cable directly into the winch and prevent it from stacking up on one side of the drum. Attach the cable as low as possible on the anchor point for the best leverage. The base of a tree, stump, or rock is generally the strongest point.

Fromwinch high speed winch system is the competition twin motor winch

Fromwinch high speed winch system is the competition twin motor winch from us that is designed to meet the needs of the serious competition events or situations a vehicle will encounter in challenge events. With its twin motors it now gives you the flexibility for hydraulic winching that can 'with the right hydraulic pump setup' allow you to achieve a twin speed hydraulic winch from a flick of a switch on your dash. It will effectively and reliably recover you and your vehicle when you most need it. Its power and recovery ability will remain constant throughout the winching process.
The car winch is part of a group of winches that have undergone extensive testing. The precision engineered, high performance winch is capable of operating in the most demanding of situations. The small compact size combined with its superior pulling power make it an ideal winch for maximum impact when faced with minimal installation space.

The profiles of double motor winch

Fromwinch electric towing winch has the motor, brake and first gear reduction on one side of the drum, and the remaining gear reductions attached at the other end.  In a double motor winch, you effectively have one set of motor, brake and all gear reductions on each end of a single drum on a single frame.
Of course, to power a double motor winch, you need twice the power of the equivalent standard winch.  For hydraulic power, the typical solution is to distribute the hydraulic flow from a common source to each motor.  For electric power, you simply provide the voltage and current demanded by the motors.  Compared to the equivalent standard model. Or it can be used with a different gear ratio or larger diameter drum to produce twice the line speed at a given line pull.

Winches has incredible potential

Fromwinch high speed winches have incredible potential if you know how to get the most power out of it. With these advanced winching techniques, you'll have a few more tricks up your sleeve when the pulling gets tough.
The length of cable you spool out also affects the power of the pull.  All electric winch motor are rated based on only one full wrap left on the drum. The less line you reel out, the less power you'll get. For a maximum power pull, unwind enough cable to leave only one layer on the drum. If your anchor point is too close to spool out enough rope, double the line with a snatch block.
Another trick to squeeze the most power out of your winch is to gas the stuck vehicle. A rolling load fuels the momentum of the pull and eases the strain on your winch. Before starting the recovery, dig out around the tires or build a rock ramp to give the stuck vehicle some traction as it begins to move.

High Speed AC Electric Winch

App: Custom made high speed AC electric clutch winch with variable speed to Draw a 90 lb kite in Surplus of 600fpm Throughout a Point and Back again for a Manufacturing Corporation with Exhibits in Japan
Collection Pull:90 lbs
Collection Pace: 660 fpm
Cable television Ability: 90′ of 1/8″ Jet cable
Energy Resource: 180 VDC Electrical
Specific Characteristics: Custom made grooved cable drum with twin anchors for positioning. Custom made 4 cam
rotary Restrict Change for failsafe Handle of the kite with cams modified to Assure tripping at high speed. 2 hp 180 VDC TEFC rated Engine with Handle board. Custom made heavy duty synthetic rope winch with PLC input.

Check out Tungsten4x4's collapsible winch cradle

Fromwinch rhino hand winch is a cost effective alternative to a vehicle mounted winch.

When heavy duty recovery work is required.  Fromwinch rhino hand winch is a cost effective alternative to a vehicle mounted winch. Providing outstanding performance and reliability, the compact and lightweight rhino hand winch is extremely durable, built using high quality steel and aluminium components.
If you want to double the power of your winch, or if the anchor point is too close to let out enough cable for a strong pull, use a snatch block to double the line.  Using a snatch block will double your load capacity and will allow you to spool out more cable to reach the maximum rating of your electric winch motor. For even more power, you can rig up a triple line pull. However, use caution with double and triple lines.  As the strength of the pull increases, so does the amount of stress placed on each rigging point. Make sure your anchor point is rock solid and can withstand the force of the pull.

The motor winch is a powerful recovery tool

Fromwinch double motor winch unit is part of a modular wire line winch unit. It can hold the direct driven winch drums.
The electric winch motor is a powerful recovery tool. Used correctly, it provides massive amounts of power to pull out your ATV or truck. With the right tools and rigging, you can pull up to two or even three times the maximum rating of your winch. The key to maximum power is knowing how to use your recovery equipment to its full potential. With these recovery tips, you'll be winching your way out of even the toughest spots just like the pros.
For starters, let's focus on rigging up a single line pull. Whenever possible, choose an anchor point directly in line with the stuck vehicle. A straight line pull is more efficient than an indirect pull. If the only option is to winch at an angle, use a snatch block to guide the cable directly into the winch and prevent it from stacking up on one side of the drum. Attach the cable as low as possible on the anchor point for the best leverage. The base of a tree, stump, or rock is generally the strongest point.

Cnmhe’s high speed electric winches

Cnmhe’s high speed electric winches, are designed for easy operation and rock-solid durability. The heavy-duty roller chain, sprockets, and roller bearings are exceptionally strong, and the phosphor bronze bearings can take whatever you can dish out. Thermostatically protected motors, machined alloy gearing, and spring-loaded electric brakes make our towboat winches a study in strength. We offer 208V or 230/460V 3- phase, 60Hz high-torque motors, with other voltages, and special marine motors available.
Safety is one of Cnmhe’s most important hallmarks with other electric clutch winch. Our towboat winches feature manual locking dogs for emergency backup use. Careful design ensures easier operation—which can reduce accidents. Our winches also feature bolted keeper plates for fast, easy shaft removal.

high speed winches are designed with either worm or spur gearing

high speed winches are designed with either worm or spur gearing.  Worm gear and shaft sets operate on perpendicular planes.  Gear sets tend to be enclosed within an oil bath.  They require less torque on input and are ideal for short distances and controlled movement.  Spur gear and shaft sets operate on parallel planes.  Gear sets are usually not enclosed and require lubrication.  They use more torque on input and are ideal for long distances and quick movement.
Heavy Duty winches are available in capacities up to 6,500 pounds for lifting or pulling applications.  They are designed with machine cut hardened worm and spur gears enclosed in an oil bath, electrically released brake, single phase or three phase motors, and self-aligning flange style ball bearings.  Alternative accessories include cable pressure bars, limit switches, grooved drums, manual overrides, and modified drum widths.  Standard design is base mounted but can be modified for wall or ceiling installation.

Capacity 12-Volt high speed electric winch

Capacity 12-Volt high speed electric winch is the ultimate winch for Extreme Terrain. It has a fully sealed drum and an unbeatable line Speed of 2 in 1 chargeable wireless remote control. It also comes equipped with a huge 6.0 HP high quality double motor winch with brass fittings, heavy duty waterproof contactors, double sealed drum on maintenance free bearings and quiet, fully sealed, efficient full steel planetary gearing. A stainless steel roller fairlead and fittings come standard with this unit. It comes complete with a heavy duty integrated wireless remote.

high speed electric winch can be driven from AC or DC sources

high speed electric winch can be driven from AC or DC sources (ship's mains or dedicated diesel electric winch) and utilize the latest technology in flux vector drives. The flux vector drive converts the input power to a variable frequency AC output with full field and armature control to drive a fully sealed zero maintenance AC motor. The controls are all solid state and permit infinitely variable speed from 2% to 100% of the maximum rated RPM while providing full torque at any RPM down to zero This feature allows full rated cable tension control at zero speed. This control feature also permits direct heave compensation (when supplied with an optional heave sensor) and bottom following which can be controlled by a tow body height above bottom using input from a bottom sensor. Other drive options include direct synchronous or 2 speed AC motors, direct DC or AC supply with SCR controlled DC output driving a DC traction type motor on the winch. These systems have microprocessor based controls similar to the flux vector drives with similar features.

Double motor winch are ideal for sheet applications

Double motor winch are ideal for sheet applications on larger yachts. In addition to the host of standard features that have made self tailing winches the benchmark for quality and performance, Fromwinch high speed winches are engineered with unsurpassed levels of functionality, monitoring and protection.
Our electric winches is a high quality European engineered and manufactured series wound motor. Fan cooled, with a powerful 3.5 kilowatt rating, it is designed specifically for 24 volt systems to minimise current draw and maximise efficiency. A carefully matched gearbox delivers the perfect balance of speed and pulling capacity - high speed at low load for fast sheeting in, and low speed at high load for safe, fine tuning when trimming.

high speed electric winches available in capacities 12500lbs

high speed electric winches, available in capacities 12.5S 12500lbs winch, are designed for easy operation and rock-solid durability. The heavy-duty roller chain, sprockets, and roller bearings are exceptionally strong, and the phosphor bronze bearings can take whatever you can dish out. Thermostatically protected motors, machined alloy gearing, and spring-loaded electric brakes make our towboat winches a study in strength. This awesome design has reduced heating of the drum during winching by a huge margin, protection of synthetic rope in high load distance pulls.
